DME/LED Conversion Kit
MD-80 LED conversion kit for no smoking/fasten seat belt sign. PMA APPROVED.
Part No. Description
P2-01-0053-002 MD-80 LED conversion kit with mounting hardware
P2-01-0053-001 MD-80 LED conversion kit without mounting hardware
DME/Escape Slide Lighting
THS lamp harness.
Part No. Description Application
P2-01-0035-001 THS-70 lamp harness A320
P2-01-0035-002 THS-71 lamp harness A320
P2-01-0035-011 THS-79 lamp harness A320
P2-01-0035-012 THS-80 lamp harness A320
P2-01-0035-030 THS-2 lamp harness 707, 727, 737 Series
P2-01-0035-050 THS-42 lamp harness 767; 767-200, -300
P2-01-0035-101 THS-119 lamp harnes 737-600, -700, -800
DME/TU-14 test unit.
Part No. Description
P7-01-0024 TU-14 test unit
DME/BAS power unit. FAA-PMA.
Model No. Spring Clip Part No. Switch Pin Part No. Cross Aircraft PMA
Reference Applications Supplement No.
BAS-5-2 P4-01-0014F120 P4-01-0014-210 ACC C15097-509 727,F100, MD80/90, 23
P4-01-0014F110 Basewest 7-1050-201 BAC 146 Series, L1011
BAS-10 P4-01-0011F120 P4-01-0011-110 Goodrich 780104-1,
ACC C15094-107		 707, 727, 737,
DC-8, DC-9,		 1
P4-01-0011-120 Basewest 7-1035-201
P4-01-0011-210
BAS-10-1 P4-01-0012F120 P4-01-0012-210 ACC C19436-113 Series A300 23
P4-01-0012F110 Basewest 7-1040-201
BAS-15 P4-01-0015F120 P4-01-0015-112 Goodrich 780108-6 767 5
P4-01-0015-212 Basewest 7-1070-201
BAS-18 P4-01-0018F120 P4-01-0018-110 Goodrich 4A3226-8 A300, A310 5
Basewest 7-1030-201 Series
BAS-19 P4-01-0019F120 P4-01-0019-210 ACC C19436-115 A300, A310 23
P4-01-0019F110 Basewest 7-1040-201 Series
BAS-20 P4-01-0031F120 P4-01-0031-210 ACC D19776 Series 757, 777 23
P4-01-0031F110 Basewest 7-1055-201
BAS-21 P4-01-0032F120 P4-01-0032-110 Goodrich 4A3396-3 767 5
Basewest 7-1060-201
BAS-23 P4-01-0033F120 P4-01-0033-210 ACC D19859-103 737 23
Basewest 7-1080-201
BAS-24 P4-01-0053F120 P4-01-0033F110 Goodrich 780114-1 737-300/400/500 5
P4-01-0053-110 Basewest 7-1075-201
BAS-25 P4-01-0054F120 P4-01-0054-110 Goodrich 780104-3 DC9, MD80 5
Basewest 7-1065-201
BAS-26 P4-01-0056F120 P4-01-0056F110 ACC 60772-101 MD-11 23
P4-01-0056-110 Basewest 7-1085-201
BAS-29 P4-01-0059F120 P4-01-0059 ACC 62974-1 777 5
BAS-30 DME780129-1 Goodrich 780129-1 737-600, -700, -800 17
Basewest 7-1045-201
DME/EPL seat mounted escape path lighting. MEETS FAR REQUIREMENTS 25.812, 25.853 AND 25.562. FAA APPROVAL
Part No. Supply Voltage Operating Voltage Battery Charging Current
Various* Varies by aircraft type 14 V DC (12 V DC nom.) 60 mA
DME/Model EF-1 flashlight. FAA-PMA APPROVED.
CONFORMS TO FAR 25.853 (a), FAR 121.210 (1) AND APPLICABLE SAE, ATA AND MILITARY SPECIFICATIONS.
Part No. Description Part No. Description
P2-07-0001-214 Beige P2-07-0001-101 Beige, no shield
P2-07-0001-215 Gray P2-07-0001-201 Beige, shield (provisions for, not included)
DME/EF-1 flashlight parts.
Part No. Description
P4-01-0021 Battery model 213, multi-cell alkaline--manganese dioxide
A1-14-0001-002 Lamp, 0.55 amps at 7.2 VDC 2700 cp initial to 450 cp at 4 hours
DME/EF-2C rechargeable flashlight.
CONFORMS TO FAR 25.853 (a), FAR 121.210 (1), AND APPLICABLE SAE, ATA, AND MILITARY SPECIFICATIONS
Part No. Power Weight
P2-07-0009-120 28 V DC 12.0 oz. (340.2 g)
P2-07-0009-110 12 V DC 20.0 oz. (567.0 g) with bracket
P2-07-0009-220 220 V AC
DME/EF-2C rechargeable flashlight parts.
Part No. Description
P4-01-0030 Battery model 315, nickel-cadmium
A1-14-0001-002 Lamp, 0.55 amps at 7.2 VDC 2700 cp initial to 450 cp at 4 hours
DME/EF-3 utility flashlight.
CONFORMS TO FAR 25.853(a), FAR 121.210(1), AND APPLICABLE SAE, ATA, AND MILITARY SPECIFICATIONS.
Part No. Weight Part No. Weight
P2-07-0012-001 6.0 oz. (173 g) P2-07-0013-001 14.1 oz. (399.8 g) with bracket
DME/Model CRS-2000 PlaneSeatTM.
MEETS 14 CFR 121.311, 14 CFR 25.853, TSO-C100b AND 16 G SEAT DYNAMIC TEST REQUIREMENTS.
Part No. Description Color
P6-01-0013-007 Child restraint device Dark gray/gray
P6-01-0013-008 Child restraint device Dark blue/blue
DME/AFAK-1 airline first aid kit.
FAA-PMA APPROVED. MEETS ALL REQUIREMENTS OF FAR PART 121, APPENDIX A AND FAR 25.853(b).
Part No.  Description Dimensions Weight
S6-01-0005-306 AFAK-1 airline first aid kit 10" x 10" x 2.625" 20 oz. container only,
57 oz. container and contents
DME/AFAK-1 airline first aid kit components.
Part No.  Description Dimensions Part No.  Description Dimensions
A1-30-0028 Gauze roller bandage Quantity A1-30-0027 Wire splint 2 each5 each
A1-30-0020 Adhesive tape 4 each A1-30-0025 Triangular bandage
A1-30-0029 Bandage scissors 1 package/2 rolls A1-30-0022 Antiseptic swabs 2 packages/ 10 each
A1-30-0024 Compress bandage, 4" 8 each D6515001-107 Latex gloves 1 package/ 2 pair
A1-30-0021 Adhesive band-aid, 1" 1 package/ 16 each 41-30-0023 Ammonia inhalants 1 package/ 10 each
DME/JAA airline first aid kit. FAA-PMA APPROVED.
CONTENTS MEET JAR-OPS 1.745 AND AMC-OPS 1.745. CANADIAN AVIATION REGULATIONS (CAR) AND FAA COMPLIANT KITS ALSO AVAILABLE.
Part No.  Description Dimensions Weight
S6-01-0005-312 JAA airline first aid standard kit 10" x 10" x 2.625" 20 oz. (.57 kg) container only,
57 oz. (1.5 kg) container and contents
DME/JAA airline first aid kit spare parts.
Part No.  Description Size
A1-30-0122-001 JAROPS spare resuscitation kit —
A1-30-0128-001 JAROPS spare burn dressing 3" x 3"
DME/SRB-10/11 survival rescue beacon. TSO C-91 (a) APPROVED.
Part No. Description Weight Frequency Temp. Operation
P3-03-0029-010* SRB-406 single antenna 24 oz. 121.5 MHz and 243.0 MHz 0˚ C to 40˚ C for 50 hours of operation
P3-03-0030--010** SRB-406 double antenna 27 oz. 121.5 MHz and 243.0 MHz 0˚ C to 40˚ C for 50 hours of operation
P4-01-0005-800 Battery pack
DME/SRB-406 single and dual antenna model survival rescue beacon. TSO-C126, TSO-C142, C/S T.001, JTSO-2C126 APPROVED.
Part No. Description Frequency
P3-03-0041-001 SRB-406 single antenna 121.5 mHz, 243.0 MHz, and 406.028 MHz
P3-03-0041--002 SRB-406 double antenna 121.5 mHz, 243.0 MHz, and 406.028 MHz
P4-03-0001-001 Battery pack —
